Resources:
Half Plate File
VIAL Compatible Firmware
Screw Specifications:
Case Screws: M2.5*6 Socket Head Hex
Weight Screws: M3*4 Countersunk Hex
Hole Dimensions: 15.3x5.8mm
Firmware Flashing Guide:
- Connect your PCB to your PC.
- Hold the button underneath the PCB while connecting it to the computer.
- A window that leads to your PCB's bootloader should appear on your file directory (it will appear as a drive).
- Drag and drop the firmware file that you want to flash into the window.
- Disconnect the PCB from your PC.
- Your new firmware should now be flashed!
